                                                                                3-Prong T-Nuts

Thread Size

Barrel Height(H)

Flange Dia(G)

Barrel Dia(F)

Prong Height(A)

Material Thickness

Drill Size

6-32

1/4

1/2

.188

1/8

.035

13/64

8-32

1/4

23/32

.208

7/32

.030

7/32

10-24

5/16

3/4

.243

7/32

.040

1/4

10-24

7/16

3/4

.243

5/16

.040

1/4

10-32

5/16

3/4

.243

7/32

.040

1/4

10-32

7/16

3/4

.243

5/16

.040

1/4

-20

1/4

3/4

.305

3/16

.047

5/16

-20

5/16

3/4

.305

7/32

.047

5/16

-20

3/8

3/4

.305

1/4

.047

5/16

-20

7/16

3/4

.305

5/16

.047

5/16

-20

1/2

3/4

.305

7/32-1/4

.047

5/16

-20

9/16

3/4

.305

1/4

.047

5/16

5/16-18

5/16

7/8

.360

9/32

.047

3/8

5/16-18

3/8

7/8

.390

1/4

.063

25/64

5/16-18

7/16

7/8

.390

1/4

.063

13/32

5/16-18

5/8

7/8

.390

5/16

.063

25/64

3/8-16

5/16

1

.420

9/32

.063

27/64

3/8-16

7/16

1

.440

11/32

.063

29/64





                                                                                 4-Prong T-Nuts

Thread Size

Barrel Height(H)

Flange Dia(G)

Barrel Dia(F)

Prong Height(A)

Material Thickness

Drill Size

6-32

1/4

1/2

.188

1/8

.035

13/64

8-32

1/4

1/2

.208

1/8

.035

7/32

10-24

5/16

3/4

.243

7/32

.040

1/4

10-24

7/16

23/32

.243

7/32

.040

1/4

10-32

5/16

3/4

.243

7/32

.040

1/4

-20

1/4

3/4

.305

7/32

.047

5/16

-20

5/16

3/4

.305

7/32

.047

5/16

-20

3/8

3/4

.305

7/32

.047

5/16

-20

7/16

3/4

.305

1/4

.047

5/16

-20

1/2

3/4

.305

7/32

.047

5/16

-20

9/16

3/4

.305

1/4

.047

5/16

5/16-18

5/16

7/8

.360

9/32

.047

3/8

5/16-18

3/8

7/8

.390

1/4

.063

25/64

5/16-18

7/16

7/8

.360

1/4

.047

3/8

5/16-18

1/2

7/8

.390

1/4

.063

13/32

5/16-18

5/8

7/8

.375-.390

1/4 -5/16

.060-.063

3/8,25/64

3/8-16

5/16

1

.440

9/32

.063

27/64

3/8-16

7/16

1

.440

11/32

.063

29/64
