Spring Nuts J Type | ||||
|
Screw Size |
Panel Range |
Length |
Width |
Material Thickness |
|
6/32 |
.025-.040 |
.47 |
.50 |
.017 |
|
6/32 |
.045-.062 |
.47 |
.50 |
.017 |
|
6/32 |
.045-.062 |
.63 |
.31 |
.017 |
|
6/32 |
.025-.040 |
.81 |
.31 |
.017 |
|
6/32 |
.045-.062 |
.81 |
.31 |
.017 |
|
6A
or B |
.025-.040 |
.47 |
.50 |
.025 |
|
6A or B |
.045-.062 |
.47 |
.50 |
.025 |
|
6A or B |
.025-.062 |
.81 |
.31 |
.025 |
|
6A or B |
.045-.062 |
.81 |
.31 |
.025 |
|
8/32 |
.025-.040 |
.53 |
.50 |
.017 |
|
8/32 |
.045-.062 |
.52 |
.50 |
.017 |
|
8/32 |
.025-.040 |
.87 |
.41 |
.017 |
|
8/32 |
.045-.062 |
.87 |
.41 |
.017 |
|
8A
or B |
.025-.045 |
.53 |
.50 |
.028 |
|
8A or B |
.045-.062 |
.53 |
.50 |
.028 |
|
8A or B |
.025-.040 |
.87 |
.41 |
.028 |
|
8A or B |
.045-.062 |
.68 |
.41 |
.028 |
|
10/24 |
.025-.040 |
.59 |
.63 |
.017 |
|
10/24 |
.045-.062 |
.59 |
.63 |
.022 |
|
10/24 |
.025-.040 |
.79 |
.38 |
.022 |
|
10/24 |
.045-.062 |
.97 |
.38 |
.022 |
|
10/32 |
.025-.040 |
.59 |
.63 |
.017 |
|
10A
or B |
.087-.110 |
.58 |
.50 |
.031 |
|
10A or B |
.045-.062 |
.58 |
.63 |
.031 |
|
10A or B |
.025-.040 |
.97 |
.50 |
.031 |
|
10A or B |
.045-.062 |
.97 |
.50 |
.031 |
Spring Nuts U Type | ||||
|
Screw Size |
Panel Range |
Length |
Width |
Material Thickness |
|
6/32 |
.025-.040 |
.48 |
.50 |
.017 |
|
6/32 |
.045-.062 |
.48 |
.50 |
.017 |
|
6/32 |
.045-.062 |
.65 |
.31 |
.017 |
|
6/32 |
.025-.040 |
.82 |
.31 |
.017 |
|
6/32 |
.045-.062 |
.83 |
.31 |
.017 |
|
6A
or B |
.025-.040 |
.48 |
.50 |
.025 |
|
6A or B |
.045-.062 |
.47 |
.50 |
.025 |
|
6A or B |
.025-.040 |
.81 |
.31 |
.025 |
|
6A or B |
.045-.062 |
.82 |
.31 |
.025 |
|
8/32 |
.025-.040 |
.52 |
.50 |
.017 |
|
8/32 |
.045-.062 |
.52 |
.50 |
.017 |
|
8/32 |
.045-.062 |
.67 |
.41 |
.017 |
|
8/32 |
.025-.062 |
.86 |
.41 |
.017 |
|
8/32 |
.045-.062 |
.87 |
.41 |
.017 |
|
8A
or B |
.025-.040 |
.52 |
.50 |
.028 |
|
8A or B |
.045-.062 |
.52 |
.50 |
.028 |
|
8A or B |
.025-.040 |
.85 |
.41 |
.028 |
|
8A or B |
.045-.062 |
.52 |
.41 |
.028 |
|
10/24 |
.025-.040 |
.58 |
.63 |
.022 |
|
10/24 |
.045-.062 |
.56 |
.63 |
.022 |
|
10/24 |
.045-.062 |
.76 |
.38 |
.022 |
|
10/24 |
.025-.040 |
.95 |
.38 |
.022 |
|
10/24 |
.045-.062 |
.95 |
.38 |
.022 |
|
10A
or B |
.025-.040 |
.56 |
.63 |
.031 |
|
10A or B |
.045-.062 |
.56 |
.63 |
.031 |
|
10A or B |
.045-.062 |
.76 |
.50 |
.031 |
|
10A or B |
.025-.040 |
.96 |
.50 |
.031 |
|
10A or B |
.045-.062 |
.95 |
.50 |
.031 |
