Spot Weld Nuts | ||||||||||||
Nut |
Pilot | |||||||||||
Size |
Width(A) |
Thickness(B) |
Length(C) |
Diameter(E) |
Height(F) |
Pilot Hole | ||||||
|
Max |
Min |
Max |
Min |
Max |
Min |
Max |
Min |
Max |
Min |
| ||
|
6-32 |
.453 |
.433 |
.097 |
.091 |
.890 |
.860 |
.198 |
.178 |
.042 |
.026 |
.203 | |
|
8-32 |
.453 |
.433 |
.097 |
.091 |
.890 |
.860 |
.213 |
.193 |
.042 |
.026 |
.219 | |
|
10-24 |
.453 |
.433 |
.097 |
.091 |
.890 |
.860 |
.244 |
.224 |
.042 |
.026 |
.250 | |
|
10-32 |
.453 |
.433 |
.097 |
.091 |
.890 |
.860 |
.244 |
.224 |
.042 |
.026 |
.250 | |
|
1/4-20 |
.453 |
.433 |
.097 |
.091 |
1.015 |
.985 |
.307 |
.272 |
.042 |
.026 |
.312 | |
|
1/4-20 |
.520 |
.495 |
.128 |
.122 |
1.140 |
1.110 |
.307 |
.287 |
.062 |
.046 |
.312 | |
|
1/4-20 |
.520 |
.495 |
.113 |
.097 |
1.015 |
.985 |
.307 |
.272 |
.054 |
.040 |
.312 | |
|
5/16-18 |
.655 |
.620 |
.145 |
.138 |
1.515 |
1.485 |
.369 |
.349 |
.092 |
.075 |
.375 | |
|
3/8-16 |
.655 |
.620 |
.145 |
.138 |
1.515 |
1.485 |
.448 |
.428 |
.102 |
.085 |
.453 | |
|
3/8-24 |
.655 |
.620 |
.145 |
.138 |
1.515 |
1.485 |
.448 |
.428 |
.102 |
.085 |
.453 | |
|
1/2-13 |
.827 |
.797 |
.192 |
.178 |
1.515 |
1.485 |
.599 |
.569 |
.102 |
.085 |
.609 | |
