                                        Two Way Reversible Lock Nuts

Nominal Dia Of Thread

Width Across Flats(F)

Width Across Corners(G)

Thickness(H)

Basic

Max

Min

Max

Min

Basic

Max

Min

8

11/32

.344

.332

.397

.378

3/16

.193

.178

10

3/8

.375

.362

.433

.413

13/64

.203

.187

1/4

7/16

.438

.428

.505

.488

7/32

.226

.212

5/16

1/2

.500

.489

.577

.557

17/64

.273

.258

3/8

9/16

.562

.551

.650

.628

21/64

.337

.320

7/16

11/16

.688

.675

.794

.768

3/8

.385

.365

1/2

3/4

.750

.736

.866

.840

7/16

.448

.427

9/16

7/8

.875

.861

1.010

.982

31/64

.496

.473

5/8

15/16

.938

.922

1.083

1.051

35/64

.559

.535

3/4

1-1/8

1.125

1.088

1.299

1.240

41/64

.665

.617

7/8

1-5/16

1.312

1.269

1.516

1.447

3/4

.776

.724

1

1-1/2

1.500

1.450

1.732

1.653

55/64

.887

.831
