Particle Board Screws

Screw Size

Head Dia.

Recess Dia.

Recess Depth

Major Dia.

Minor Dia.

Max

Min

Max

Max

Min

Max

Min

Max

Min

6

.333

.312

.189

.107

.087

.142

.135

.089

.080

8

.336

.326

.205

.122

.115

.168

.161

.104

.094

10

.340

.319

.221

.142

.137

.194

.186

.120

.110
