Nylon Insert Lock Nuts, NE Pattern NominalSize Width Across Flats(F) Thickness(H) Side Height(I) Width Across Corners(G) Basic Max Min Max Min Ref Ref 6 5/16 .313 .305 .188 .168 .103 .339 8 11/32 .345 .336 .239 .219 .140 .374 10 3/8 .376 .367 .249 .229 .140 .410 1/4 7/16 .439 .430 .328 .298 .225 .482 5/16 1/2 .502 .492 .359 .329 .250 .552 3/8 9/16 .564 .553 .468 .438 .335 .622 7/16 5/8 .627 .616 .468 .438 .324 .698 1/2 3/4 .752 .741 .609 .579 .464 .837 9/16 7/8 .877 .865 .656 .626 .469 .978 5/8 15/16 .940 .928 .765 .735 .593 1.051 3/4 1-1/8 1.064 1.052 .890 .860 .742 1.191 7/8 1-5/16 1.252 1.239 .999 .969 .790 1.403 1 1-1/2 1.440 1.427 1.078 1.016 .825 1.615 1-1/8 1-11/16 1.627 1.614 1.203 1.141 .930 1.826 1-1/4 1-7/8 1.815 1.801 1.422 1.360 1.125 2.038 1-1/2 2-1/4 2.197 2.159 1.640 1.578 1.313 2.444
|
Nylon Insert Lock Nuts, NTE Pattern | |||||||
|
NominalSize |
Width Across Flats(F) |
Thickness(H) |
Side Height(I) |
Width Across Corners(G) | |||
|
Basic |
Max |
Min |
Max |
Min |
Ref |
Ref | |
|
4 |
1/4 |
.251 |
.243 |
.124 |
.094 |
.075 |
.268 |
|
6 |
5/16 |
.313 |
.305 |
.140 |
.110 |
.090 |
.339 |
|
8 |
11/32 |
.345 |
.336 |
.187 |
.157 |
.110 |
.374 |
|
10 |
3/8 |
.376 |
.367 |
.187 |
.157 |
.110 |
.410 |
|
1/4 |
7/16 |
.439 |
.430 |
.218 |
.188 |
.125 |
.482 |
|
5/16 |
1/2 |
.502 |
.492 |
.265 |
.235 |
.158 |
.552 |
|
3/8 |
9/16 |
.564 |
.553 |
.281 |
.251 |
.150 |
.622 |
|
7/16 |
5/8 |
.627 |
.615 |
.328 |
.298 |
.225 |
.694 |
|
1/2 |
3/4 |
.752 |
.741 |
.328 |
.298 |
.190 |
.837 |
|
9/16 |
7/8 |
.877 |
.865 |
.374 |
.344 |
.225 |
.978 |
|
5/8 |
15/16 |
.940 |
.928 |
.406 |
.376 |
.265 |
1.051 |
|
3/4 |
1-1/8 |
1.064 |
1.052 |
.421 |
.391 |
.288 |
1.191 |
|
7/8 |
1-1/4 |
1.252 |
1.239 |
.484 |
.454 |
.340 |
1.403 |
