                     FENDER WASHER         ANSI/ASME B18.22.1

Bolt size

Inside Dia.

Outside Dia.

Thickness

Max

Min

10

7/32

11/16

.080

.051

10

7/32

3/4

.080

.051

10

7/32

7/8

.080

.051

10

7/32

1

.080

.051

10

7/32

1-1/4

.080

.051

10

7/32

1-1/2

.080

.051

10

7/32

2

.080

.051

1/4

9/32

1

.080

.051

1/4

9/32

1-1/4

.080

.051

1/4

9/32

1-1/2

.080

.051

1/4

9/32

1-3/4

.080

.051

1/4

9/32

2

.080

.051

5/16

11/32

1

.080

.051

5/16

11/32

1-1/4

.080

.051

5/16

11/32

1-1/2

.080

.051

5/16

11/32

2

.080

.051

5/16

11/32

2-1/2

.080

.051

3/8

13/32

1-1/4

.080

.051

3/8

13/32

1-1/2

.080

.051

3/8

13/32

1-3/4

.080

.051

3/8

13/32

2

.080

.051

3/8

13/32

2-1/2

.080

.051

1/2

17/32

1-1/4

.080

.051

1/2

17/32

1-1/2

.080

.051

1/2

17/32

1-3/4

.080

.051

1/2

17/32

2

.080

.051

1/2

17/32

2-1/2

.080

.051

1/2

17/32

3

.080

.051

5/8

11/16

1-1/4

.084

.074

3/4

13/16

2

.080

.051

7/8

15/16

2-1/2

.118

.101
