Butt Connectors(Seamless)Non-Insulated | |||
|
Wire Size |
Dimensions | ||
|
Length |
B |
A | |
|
26-22 |
.385 |
.079 |
.039 |
|
22-16 |
.591 |
.130 |
.067 |
|
16-14 |
.591 |
.162 |
.091 |
|
12-10 |
.690 |
.213 |
.134 |
Butt Connectors(Vinyl Seamless)Insulated | ||||
|
Wire Size |
Dimensions | |||
|
Inside Dia. |
Length |
B |
A | |
|
22-16 |
.156 .156 |
.894 1.07 |
.067 .067 |
.591 .591 |
|
16-14 |
.177 .177 |
.894 1.07 |
.091 .091 |
.591 .591 |
|
12-10 |
.268 |
1.07 |
.134 |
.690 |
Butt Connectors(Vinyl Butted Seam)Insulated | ||||
|
Wire Size |
Dimensions | |||
|
Inside Dia. |
Length |
B |
G | |
|
22-16 |
.158 .158 .158 |
.894 1.07 1.02 |
.067 .067 .067 |
.591 .591 .591 |
|
16-14 |
.177 .177 .177 |
.894 1.07 1.02 |
.091 .091 .091 |
.591 .591 .591 |
|
12-10 |
.268 .268 |
1.07 1.07 |
.134 .134 |
.690 .690 |
Butt Connectors(Nylon Seamless)Insulated | ||||
|
Wire Size |
Dimensions | |||
|
Inside Dia. |
Length |
B |
G | |
|
26-22 |
.080 |
.850 |
.039 |
.385 |
|
22-18 |
.120 |
.985 |
.061 |
.650 |
|
22-16 |
.158 .126 |
.894 1.03 |
.067 .067 |
.591 .650 |
|
16-14 |
.177 .154 .154 |
.894 1.05 1.10 |
.091 .091 .091 |
.591 .650 .650 |
|
12-10 |
.268 .213 .213 |
1.05 1.29 1.20 |
.134 .134 .134 |
.690 .810 .810 |
