                                                     Blind Rivets                                                       SAE J200

MAY98

Rivet Series No.

Nom Rivet Size

Recommended Drill Size

Recommended Hole Size

Rivet No.

Grip Range

Rivet Body Length(L)

Max

Min



3



3/32

0.0938



#41



.100



.097

32

.020-.125

.250

34

.126-.250

.375

36

.251-.375

.500







4







1/8

.1250







#30







.133







.129

41

.020-.062

.212

42

.063-.125

.275

43

.126-.187

.337

44

.188-.250

.400

45

.251-.312

.462

46

.313-.375

.525

48

.376-.500

.650

410

.501-.625

.775





5





5/32

.1562





#20





.164





.160

52

.020-.125

.300

53

.126-.187

.362

54

.188-.250

.425

56

.251-.375

.550

58

.376-.500

.675

510

.501-.625

.800









6









3/16

.1875









#11









.196









.192

62

.020-.125

.325

63

.126-.187

.387

64

.188-.250

.450

66

.251-.375

.575

68

.376-.500

.700

610

.501-.625

.825

612

.626-.750

.950

614

.751-.875

1.075

616

.876-.1000

1.200

618

1.001-1.125

1.325









8









1/4

.250









F









.261









.257

82

.020-.125

.375

84

.126-.250

.500

86

.251-.375

.625

88

.376-.500

.750

810

.501-.625

.875

812

.626-.750

1.000

814

.751-.875

1.125

816

.876-.1000

1.250

818

1.001-1.125

1.375

820

1.126-1.250

1.500


Dimensions of Regular and Large

Rivet Series No.

Nom Rivet Size

Body Dia.(D)

Regular Head

         Large Head

Radius

of Fillet

Mandrel Dia(W)

Mandrel Protrusion(N)

Blind Side Protrusion(F)

Max

Min

Head Dia.(H)

Head Height(E)

Head Dia.(H)

Head Height(E)

Max

Min

Max

Max

Min

Max

    Max

Nom

Min

Max

3

3/32

.096

.090

.198

.178

.032

.293

.269

.040

.015

.057

1.00

L + .100

4

1/8

.128

.122

.262

.238

.040

.390

.360

.065

.020

.076

1.00

L + .120

5

5/32

.159

.153

.328

.296

.050

.488

.448

.075

.020

.095

1.00

L + .140

6

3/16

.191

.183

.394

.356

.060

.650

.600

.092

.025

.114

1.00

L + .160

8

1/4

.255

.246

.525

.475

.080

.780

.720

.107

.030

.151

1.00

L + .180
